WHAT IS OILWATCH

Oilwatch is a range of cost effective oil monitoring systems for the workshop environment. It allows the garage owner to retain control and security of his bulk liquid dispensing, whilst maintaining the necessary flexibility required in today's busy and ever changing workshops.

HOW DOES OILWATCH WORK?

Oilwatch operates via a number of uniquely intelligent keypad entry units controlling the fluid flow by opening and closing solenoid valves installed at the outlet. The volume dispensed is measured by a meter sending a digital signal back to the keypad for correlation.

WHY INSTALL OILWATCH?

Oilwatch is designed to help customers retain the flexibility of non-monitored bulk oil supply installations. In today's market place it is more important than ever to ensure businesses are as efficient as possible. Accurate dispensing makes monitoring a cost effective solution for large or small companies bulk liquids. Companies wishing to improve their bulk oil installations and reduce their losses from unrecorded deliveries will find the Oilwatch systems reporting capability comprehensive and easy to use. Oilwatch is used in many countries throughout the world. The flexibility and quality of the Oilwatch system design has made it an essential modern management tool reducing waste, controlling cost and increasing profits.

OILWATCH SYSTEM TYPES

Oilwatch can be supplied in a number of different configurations including:

• Standard Oilwatch
• Compact Oilwatch
• P.C. Oilwatch

TECHNICAL SPECIFICATION

PC INTERFACE

Input - 24V AC

Outputs

2 x RS232 for printer and PC.

1 x RS485 for Oilwatch Network.

MASTER CONTROLLER

Input - 24V AC.

Outputs

RS232 Printer data cable.

RS485 for Oilwatch Network.

KEYPAD

Input

24v AC 0.5A per keypad unit.

Pulse meter input 2 - core screened.

System communications - 4 wire RS485.

Outputs

24v AC switched for solenoid valves

Pulser cable for large digital display

POWER SUPPLY

Input - 240 / 220v AC

Outputs

24v AC switched

240 / 220v AC switched for printer.

DIGITAL DISPLAY

Inputs

24v AC

Pulser input 4 - core screened.

METERS

Flow Range 1 to 35 l/min.

Operating pressure 0.35 to 70 bar.

Operating temperature -20 to +50 °C.

Accuracy ± 0.5%

1/2" BSP Inlet/Outlet connection.

SOLENOIDS

Flow range 1 to 35 l/min

operating pressure max. 207 bar

operating temperature -40 to 120 °C.

1/2" BSP inlet/outlet.

PRINTERS

Two high speed 40 column receipt printers are now available for use with Oilwatch systems. Our standard printer features include: automatic cutter and take up spool for use with two ply paper, easy paper roll replacement and automatic paper loading, two colour printing for low stock warnings and invalid system usage.

The second printer available in the Oilwatch product range is specified for use with the Pc Oilwatch. This printer features; Single colour printing, and relies on the Pc programme for duplicating transaction data. If required it can be installed for operation with either the Standard or Compact Oilwatch.

ANCILLARY EQUIPMENT

OILWATCH PRODUCTS

Only original Permex or Permex recommended parts must be used. Failure to do so will invalidate warranty. For technical queries consult your distributor or contact us directly.
